| İletken | EN 60228 Sınıf 5 |
|---|---|
| Yalıtkan | EN 50363-3 TI2 PVC Kompaund |
| Yalıtım Renk | DIN VDE 0293; TS EN 50334 veya Siyah yalıtkan, beyaz numara kodlu |
| Büküm | Uygun adımda katlar halinde |
| Ayırıcı Bant | PES Bant |
| Ekran | Kalaylı Bakır Örgü |
| Kılıf | EN 50363-4-1 TM2 PVC Kompaund |
| Kılıf Rengi | RAL 7001 Gri |
| İLETKEN DİRENCİ (max.) | YALITIM DİRENCİ (min.) | AKIM TAŞIMA KAPASİTESİ | ÇALIŞMA VOLTAJI | TEST VOLTAJI | BÜKÜLME YARIÇAPI | ÇALIŞMA SICAKLIĞI | ALEV GECİKTİRİCİLİK TESTİ | ||
|---|---|---|---|---|---|---|---|---|---|
| mm² 0,5 0,75 1 1,5 2,5 | Ω/km 39 26 19,5 13,3 7,98 | 20MΩxkm | mm² 0,5 0,75 1 1,5 2,5 | A 6 13 16 20 25 | 300V/500V | 4000 V | 10x Kablo Ø | -30˚C ~ +70˚C Sabit +5˚C ~ +70˚C Hareketli | EN 60332-1-2 |
| KOD NO | DAMAR SAYISI VE KESİTİ (mm²) | KABLO ÇAPI (mm) | BAKIR AĞIRLIĞI (kg/km) | YAKLAŞIK KABLO AĞIRLIĞI (kg/km) |
|---|---|---|---|---|
| MDER001000200050G | 2 x 0,50 | 5,3 | 18 | 38 |
| MDER000900300050G | 3 x 0,50 | 5,6 | 25 | 46 |
| MDER000900400050G | 4 x 0,50 | 6,2 | 30 | 58 |
| MDER000900500050G | 5 x 0,50 | 6,7 | 37 | 69 |
| MDER000900600050G | 6 x 0,50 | 7,2 | 42 | 79 |
| MDER000900700050G | 7 x 0,50 | 7,2 | 47 | 84 |
| MDER000900800050G | 8 x 0,50 | 7,9 | 54 | 101 |
| MDER000901000050G | 10 x 0,50 | 9,3 | 66 | 125 |
| 0 | ||||
| MDER001000200075G | 2 x 0,75 | 5,2 | 25 | 46 |
| MDER000900300075G | 3 x 0,75 | 6,2 | 33 | 59 |
| MDER000900400075G | 4 x 0,75 | 6,7 | 43 | 72 |
| MDER000900500075G | 5 x 0,75 | 7,2 | 50 | 84 |
| MDER000900600075G | 6 x 0,75 | 8 | 60 | 103 |
| MDER000900700075G | 7 x 0,75 | 8 | 68 | 110 |
| MDER000900800075G | 8 x 0,75 | 8,6 | 78 | 127 |
| MDER000901000075G | 10 x 0,75 | 10,1 | 95 | 157 |
| MDER001000200100G | 2 x 1 | 6,3 | 30 | 57 |
| MDER000900300100G | 3 x 1 | 6,6 | 43 | 69 |
| MDER000900400100G | 4 x 1 | 7,2 | 53 | 84 |
| MDER000900500100G | 5 x 1 | 8 | 65 | 105 |
| MDER000900600100G | 6 x 1 | 8,6 | 78 | 122 |
| MDER000900700100G | 7 x 1 | 8,6 | 88 | 132 |
| MDER000900800100G | 8 x 1 | 9,4 | 99 | 157 |
| MDER000901000100G | 10 x 1 | 11,1 | 124 | 195 |
| 0 | ||||
| MDER001000200150G | 2 x 1,5 | 6,7 | 41 | 68 |
| MDER000900300150G | 3 x 1,5 | 6,6 | 56 | 69 |
| MDER000900400150G | 4 x 1,5 | 7,2 | 73 | 84 |
| MDER000900500150G | 5 x 1,5 | 8 | 89 | 105 |
| MDER000900600150G | 6 x 1,5 | 8,6 | 105 | 122 |
| MDER000900700150G | 7 x 1,5 | 8,6 | 121 | 132 |
| MDER000900800150G | 8 x 1,5 | 9,4 | 137 | 157 |
| MDER000901000150G | 10 x 1,5 | 11,1 | 171 | 195 |
| MDER001000200250G | 2 x 2,5 | 8,1 | 63 | 109 |
| MDER000900300250G | 3 x 2,5 | 8,5 | 89 | 126 |
| MDER000900400250G | 4 x 2,5 | 9,5 | 116 | 163 |
| MDER000900500250G | 5 x 2,5 | 10,5 | 143 | 202 |
| MDER000900600250G | 6 x 2,5 | 11,4 | 170 | 238 |
| MDER000900700250G | 7 x 2,5 | 11,4 | 195 | 260 |
| MDER000900800250G | 8 x 2,5 | 12,5 | 222 | 307 |
| MDER000901000250G | 10 x 2,5 | 14,9 | 277 | 387 |
