| İletken | EN 60228 Sınıf 5 Bükülü Elektrolitik Tavlı Bakır |
|---|---|
| Yalıtkan | Özel PVC Kompaund |
| Yalıtım Renk | DIN VDE 0293; TS EN 50334 veya Siyah yalıtkan, beyaz numara kodlu |
| Büküm | Uygun adımda katlar halinde |
| Kılıf | EN 50363-4-1 TM2 PVC Kompaund |
| Kılıf Rengi | RAL 7001 Gri |
| İLETKEN DİRENCİ (max.) | YALITIM DİRENCİ (min.) | AKIM TAŞIMA KAPASİTESİ | ÇALIŞMA VOLTAJI | TEST VOLTAJI | BÜKÜLME YARIÇAPI | ÇALIŞMA SICAKLIĞI | ALEV GECİKTİRİCİLİK TESTİ | ||
|---|---|---|---|---|---|---|---|---|---|
| mm² 0,5 0,75 1 1,5 2,5 | Ω/km 39 26 19,5 13,3 7,98 | MΩxKm 20 MΩ.km | mm² 0,5 0,75 1 1,5 2,5 | A 6 13 16 20 25 | 300 / 500 V | 4000 V | 7,5x Kablo Ø | -30˚C ~ +70˚C Sabit -5˚C ~ +70˚C Hareketli | EN 60332-1-2 |
| KOD NO | DAMAR SAYISI VE KESİTİ (mm²) | KABLO ÇAPI (mm) | BAKIR AĞIRLIĞI (kg/km) | YAKLAŞIK KABLO AĞIRLIĞI (kg/km) |
|---|---|---|---|---|
| MDER000100200050G | 2 x 0,50 | 4,8 | 10 | 36 |
| MDER000200300050G | 3 x 0,50 | 5,1 | 15 | 43 |
| MDER000200400050G | 4 x 0,50 | 5,5 | 19 | 51 |
| MDER000200500050G | 5 x 0,50 | 6,2 | 24 | 63 |
| MDER000200600050G | 6 x 0,50 | 6,7 | 29 | 74 |
| MDER000200700050G | 7 x 0,50 | 6,7 | 34 | 79 |
| MDER000200800050G | 8 x 0,50 | 7,2 | 36 | 86 |
| MDER000201000050G | 10 x 0,50 | 8,6 | 48 | 120 |
| MDER000201200050G | 12 x 0,50 | 8,6 | 58 | 127 |
| MDER000201400050G | 14 x 0,50 | 9,5 | 67 | 152 |
| MDER000201600050G | 16 x 0,50 | 10 | 77 | 169 |
| MDER000201800050G | 18 x 0,50 | 10,7 | 86 | 208 |
| MDER000201900050G | 19 x 0,50 | 10,7 | 91 | 213 |
| MDER000202100050G | 21 x 0,50 | 11,2 | 101 | 244 |
| MDER000202400050G | 24 x 0,50 | 12,3 | 115 | 291 |
| MDER000203000050G | 30 x 0,50 | 13,5 | 144 | 333 |
| MDER000203600050G | 36 x 0,50 | 14,7 | 173 | 404 |
| MDER000100200075G | 2 x 0,75 | 5,2 | 14 | 45 |
| MDER000200300075G | 3 x 0,75 | 5,5 | 22 | 53 |
| MDER000200400075G | 4 x 0,75 | 6,2 | 29 | 68 |
| MDER000200500075G | 5 x 0,75 | 6,7 | 36 | 80 |
| MDER000200600075G | 6 x 0,75 | 7,5 | 43 | 97 |
| MDER000200700075G | 7 x 0,75 | 7,5 | 50 | 105 |
| MDER000200800075G | 8 x 0,75 | 8,1 | 58 | 116 |
| MDER000201000075G | 10 x 0,75 | 9,6 | 72 | 159 |
| MDER000201200075G | 12 x 0,75 | 9,6 | 86 | 169 |
| MDER000201400075G | 14 x 0,75 | 10,6 | 101 | 201 |
| MDER000201600075G | 16 x 0,75 | 11,1 | 115 | 223 |
| MDER000201800075G | 18 x 0,75 | 11,9 | 130 | 254 |
| MDER000201900075G | 19 x 0,75 | 11,9 | 137 | 261 |
| MDER000202100075G | 21 x 0,75 | 12,5 | 151 | 279 |
| MDER000202400075G | 24 x 0,75 | 13,6 | 173 | 332 |
| MDER000203000075G | 30 x 0,75 | 15 | 216 | 407 |
| MDER000203600075G | 36 x 0,75 | 16,3 | 259 | 481 |
| MDER000100200100G | 2 x 1 | 5,6 | 19 | 53 |
| MDER000200300100G | 3 x 1 | 6,1 | 29 | 68 |
| MDER000200400100G | 4 x 1 | 6,7 | 38 | 82 |
| MDER000200500100G | 5 x 1 | 7,5 | 48 | 102 |
| MDER000200600100G | 6 x 1 | 8,1 | 58 | 118 |
| MDER000200700100G | 7 x 1 | 8,1 | 67 | 128 |
| MDER000200800100G | 8 x 1 | 8,9 | 77 | 145 |
| MDER000201000100G | 10 x 1 | 10,6 | 96 | 198 |
| MDER000201200100G | 12 x 1 | 10,6 | 115 | 212 |
| MDER000201400100G | 14 x 1 | 11,5 | 134 | 246 |
| MDER000201600100G | 16 x 1 | 12,3 | 154 | 281 |
| MDER000201800100G | 18 x 1 | 12,9 | 173 | 310 |
| MDER000201900100G | 19 x 1 | 12,9 | 182 | 320 |
| MDER000202100100G | 21 x 1 | 13,7 | 202 | 346 |
| MDER000202400100G | 24 x 1 | 15 | 230 | 415 |
| MDER000203000100G | 30 x 1 | 16,5 | 288 | 507 |
| MDER000203600100G | 36 x 1 | 17,9 | 346 | 599 |
| MDER000100200150G | 2 x 1,5 | 6,2 | 29 | 68 |
| MDER000200300150G | 3 x 1,5 | 6,6 | 43 | 84 |
| MDER000200400150G | 4 x 1,5 | 7,2 | 58 | 102 |
| MDER000200500150G | 5 x 1,5 | 8 | 72 | 126 |
| MDER000200600150G | 6 x 1,5 | 8,9 | 86 | 152 |
| MDER000200700150G | 7 x 1,5 | 8,9 | 101 | 165 |
| MDER000200800150G | 8 x 1,5 | 9,6 | 115 | 182 |
| MDER00020100150G | 10 x 1,5 | 11,4 | 144 | 248 |
| MDER00020120150G | 12 x 1,5 | 11,4 | 173 | 268 |
| MDER00020140150G | 14 x 1,5 | 12,6 | 202 | 318 |
| MDER00020160150G | 16 x 1,5 | 13,4 | 230 | 362 |
| MDER00020180150G | 18 x 1,5 | 14,1 | 259 | 400 |
| MDER00020190150G | 19 x 1,5 | 14,1 | 274 | 414 |
| MDER00020210150G | 21 x 1,5 | 15 | 302 | 445 |
| MDER00020240150G | 24 x 1,5 | 16,3 | 346 | 533 |
| MDER00020300150G | 30 x 1,5 | 18 | 432 | 655 |
| MDER00020360150G | 36 x 1,5 | 19,5 | 518 | 774 |
| MDER000100200250G | 2 x 2,5 | 7,6 | 48 | 129 |
| MDER000200300250G | 3 x 2,5 | 8 | 72 | 164 |
| MDER000200400250G | 4 x 2,5 | 9 | 96 | 197 |
| MDER000200500250G | 5 x 2,5 | 98,8 | 120 | 238 |
| MDER000200600250G | 6 x 2,5 | 10,9 | 144 | 238 |
| MDER000200700250G | 7 x 2,5 | 10,9 | 168 | 260 |
| MDER000200800250G | 8 x 2,5 | 12 | 192 | 294 |
| MDER000201000250G | 10 x 2,5 | 14,2 | 240 | 396 |
| MDER000201200250G | 12 x 2,5 | 14,2 | 288 | 431 |
| MDER000201400250G | 14 x 2,5 | 15,6 | 336 | 507 |
| MDER000201600250G | 16 x 2,5 | 16,6 | 384 | 577 |
| MDER000201800250G | 18 x 2,5 | 17,7 | 432 | 648 |
| MDER000201900250G | 19 x 2,5 | 17,7 | 456 | 671 |
| MDER000202100250G | 21 x 2,5 | 18,6 | 504 | 714 |
| MDER000202400250G | 24 x 2,5 | 20,2 | 576 | 850 |
| MDER000203000250G | 30 x 2,5 | 22,4 | 720 | 1051 |
| MDER000203600250G | 36 x 2,5 | 24,3 | 864 | 1243 |
