| İletken | EN 60228 Class 5 Bükülü Elektrolitik Bakır |
|---|---|
| Yalıtkan | EN 50363-1 EI2 Çapraz Bağlı Seramik Formunda Polimer Kompaund |
| Yalıtım Renk | HD 308 S2 |
| Büküm | Uygun adımda katlar halinde |
| Kılıf | IEC 60502-1 HFFR Kompaund |
| Kılıf Rengi | RAL2003 Turuncu |
| Mevcut Kesitler | 1,5 - 50 mm² |
| İLETKEN DİRENCİ (max.) | ÇALIŞMA VOLTAJI | TEST VOLTAJI | BÜKÜLME ÇAPI (min.) | ÇALIŞMA SICAKLIĞI | SHORT CIRCUIT TEMPERATURE | YALITIM DİRENCİ (min.) | |
|---|---|---|---|---|---|---|---|
| Ω/km 12,1 7,41 4,61 3,08 1,83 1,15 0,727 0,554 0,386 | mm² 1,5 2,5 4 6 10 16 25 35 50 | 0,6/1 kV | 4000 V | 12 x Ø | -40°C ~ + 90°C (Fixed Laying) | +250˚C | 100 MΩ x km |
| KOD NO | DAMAR SAYISI VE KESİTİ | KABLO ÇAPI (mm) | YAKLAŞIK KABLO AĞIRLIĞI (kg/km) | BAKIR AĞIRLIĞI (kg/km) |
|---|---|---|---|---|
| MDER130600200150O | 2 x 1,5 | 9,8 | 141 | 29 |
| MDER130700300150O | 3 x 1,5 | 10,3 | 161 | 43 |
| MDER130700400150O | 4 x 1,5 | 11,1 | 190 | 58 |
| MDER130700500150O | 5 x 1,5 | 12 | 226 | 72 |
| MDER130600200250O | 2 x 2,5 | 10,6 | 174 | 48 |
| MDER130700300250O | 3 x 2,5 | 11,1 | 202 | 72 |
| MDER130700400250O | 4 x 2,5 | 12 | 240 | 96 |
| MDER130700500250O | 5 x 2,5 | 13,1 | 291 | 120 |
| MDER130600200400O | 2 x 4 | 12,4 | 245 | 77 |
| MDER130700300400O | 3 x 4 | 13,1 | 291 | 115 |
| MDER130700400400O | 4 x 4 | 14,2 | 348 | 154 |
| MDER130700500400O | 5 x 4 | 15,5 | 422 | 192 |
| MDER130600200600O | 2 x 6 | 13,6 | 309 | 115 |
| MDER130700300600O | 3 x 6 | 14,4 | 372 | 173 |
| MDER130700400600O | 4 x 6 | 15,7 | 450 | 230 |
| MDER130700500600O | 5 x 6 | 17,1 | 548 | 288 |
| MDER130600201000O | 2 x 10 | 15,6 | 438 | 192 |
| MDER130700301000O | 3 x 10 | 16,5 | 536 | 288 |
| MDER130700401000O | 4 x 10 | 18,1 | 668 | 384 |
| MDER130700501000O | 5 x 10 | 19,8 | 812 | 480 |
| MDER130500101600O | 1 x 16 | 9,8 | 222 | 154 |
| MDER130700301600O | 3 x 16 | 18,5 | 735 | 461 |
| MDER130700401600O | 4 x 16 | 20,5 | 929 | 614 |
| MDER130700501600O | 5 x 16 | 22,2 | 1125 | 768 |
| MDER183000102500O | 1 x 25 | 11,3 | 325 | 240 |
| MDER130700302500O | 3 x 25 | 21,9 | 1095 | 720 |
| MDER130700402500O | 4 x 25 | 24,4 | 1382 | 960 |
| MDER130700502500O | 5 x 25 | 26,6 | 1693 | 1200 |
| MDER183000103500O | 1 x 35 | 12,5 | 427 | 336 |
| MDER130700303500O | 3 x 35 | 24,5 | 1443 | 1008 |
| MDER130700403500O | 4 x 35 | 27 | 1828 | 1344 |
| MDER130700503500O | 5 x 35 | 30 | 2265 | 1680 |
| MDER130500105000O | 1 x 50 | 14,3 | 590 | 480 |
| MDER130700305000O | 3 x 50 | 28,6 | 2024 | 1440 |
| MDER130700405000O | 4 x 50 | 31,8 | 2592 | 1920 |
| MDER130700505000O | 5 x 50 | 35,3 | 3200 | 2400 |
| ALEV GECİKTİRİCİLİK | ALEV YAYILMASI | DUMAN YOĞUNLUĞU TESTİ | KOROZİF GAZ TESTİ | HALOJENSİZLİK | DEVRE BÜTÜNLÜĞÜ TESTİ (FE180) | MEKANİK ŞOKLU DEVRE BÜTÜNLÜĞÜ TESTİ (PH120) |
|---|---|---|---|---|---|---|
| EN 60332-1-2 | EN IEC 60332-3-24 (CAT.C) | EN 61034-2 | EN 60754-2 | EN 60754-1 | IEC 60331-21 | EN 50200 EN 60331-1 |
